ABB

1SDA061839R1 ABB

ABB EcoSolutions

Material Compliance

RoHS Information:
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Conflict Minerals Reporting Template (CMRT):
Toxic Substances Control Act - TSCA:
SCIP:
7d774f52-3346-4f24-899a-e8521af5c289 Italy
Simplified SCIP:
ac2a53c9-d557-454e-a5b7-3e42088387f6 Germany
40bc0225-f4b2-47e6-b5ac-db0af8446c45 Estonia
2b688f1d-0ce5-47d9-b901-5b065093be57 Bulgaria
7644b113-6a15-4609-8896-79f212445121 Greece
73dd22b9-ffbb-4402-88b3-389e904de91b Netherlands
7a4c94b7-58db-468f-bd24-aac1b5d623ff Portugal
433afecd-8138-40a8-aa4d-3359c9d3d543 Poland
3a7b9049-97b3-4661-b05a-01effdd58791 Sweden
bd11c588-2d0c-4d62-899a-dddc13ee34ca Czech Republic
4977211c-f6aa-4ca2-9eb8-46308e34b9b7 Poland
a06c380c-a657-4c33-9012-fdc0bff1e31b Hungary
d8ec61a0-065e-47d1-af14-e28699cf04ed Sweden
91f8b482-91a9-4d60-85ed-0a7f0102fd29 Denmark
19ac6957-4f60-4e6e-be6a-21dbc6887229 Croatia
7d78e07c-cdb3-44c7-905e-6bf68dd8ba18 Germany
2d3c803f-6bb9-4baf-9da3-5a6f81295909 Germany
ff4094a1-d0e2-4b27-9de4-e5eabe3a29ac France
6b79f1d1-5652-40c2-8730-99c2dd7e50f0 Germany
fedca93b-ed48-4719-8d66-b98ddc839b27 Norway
72fac297-796b-49b6-a264-4564bbe03d31 Poland
57f638eb-7f35-47c9-8fc0-e41fb520c62c Finland
aa96d004-0b9b-4e41-8855-ddec53933a18 Belgium
52f5555d-0b88-47a6-88b0-9226af9d5aae Belgium
29241b65-1694-457b-a67c-5ac5182fb241 France
c35aa013-ee79-46c3-ac9e-1ea60cc9e698 Spain
ab6e676e-2dd6-444d-bbd0-37b7465922f9 Hungary
ed2597f9-7547-4212-9ae9-0893abad1519 Germany
ac2a53c9-d557-454e-a5b7-3e42088387f6 Germany
40bc0225-f4b2-47e6-b5ac-db0af8446c45 Estonia
2b688f1d-0ce5-47d9-b901-5b065093be57 Bulgaria
7644b113-6a15-4609-8896-79f212445121 Greece
73dd22b9-ffbb-4402-88b3-389e904de91b Netherlands
7a4c94b7-58db-468f-bd24-aac1b5d623ff Portugal
433afecd-8138-40a8-aa4d-3359c9d3d543 Poland
3a7b9049-97b3-4661-b05a-01effdd58791 Sweden
bd11c588-2d0c-4d62-899a-dddc13ee34ca Czech Republic
4977211c-f6aa-4ca2-9eb8-46308e34b9b7 Poland

Ordering

Order Code US and Canada:
T5S600BW
EAN:
8015644643645
Minimum Order Quantity:
1 piece
Customs Tariff Number:
85362090

Dimensions

Product Net Width:
140 mm
Product Net Height:
205 mm
Product Net Depth / Length:
103.5 mm
Product Net Weight:
5.1 kg

Container Information

Package Level 1 EAN:
8015644643645

Additional Information

Product Main Type:
SACE Tmax T
Product Name:
Moulded Case Circuit Breaker
Product Type:
Automatic Circuit Breaker
Suitable For:
T5
Suitable for Product Class:
Moulded Case Circuit Breakers
Version:
F

Technical

Mechanical Durability:
20000 cycle
120 cycles per hour
20000 cycle
120 cycles per hour
Number of Poles:
3P
Power Loss:
at Rated Operating Conditions per Pole 37.1 W
Rated Current (In):
600 A
Rated Impulse Withstand Voltage (Uimp):
8 kV
Rated Insulation Voltage (Ui):
1000 V
Rated Operational Voltage:
600 V AC
Rated Uninterrupted Current (Iu):
600 A
Release:
PR221DS-LS/I
Release Type:
EL
Short-Circuit Performance Level:
S
Standards:
UL
Sub-type:
T5
Terminal Connection Type:
Fixed Circuit-Breakers
Front
Fixed Circuit-Breakers
Front
Test Voltage Max (Utest):
3500 V

Technical UL/CSA

Interrupting Rating acc. to UL489:
(240 V AC) 100 kA
(480 V AC) 35 kA
(600 V AC) 25 kA
(240 V AC) 100 kA
(480 V AC) 35 kA
(600 V AC) 25 kA

Certificates and Declarations

External Classifications and Standards

ETIM 9:
EC000228 - Power circuit-breaker for trafo/generator/installation protection
ETIM 10:
EC000228 - Power circuit-breaker for trafo/generator/installation protection
IDEA Granular Category Code (IGCC):
4932 >> 3 Pole Non-Interchangeable Trip Electronic Circuit Breakers
UNSPSC:
39121616
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
eClass:
V11.1 : 27370409

Sale price€4.689,95
1-year warranty
FREE WORDWIDE SHIPPING
Est. delivery between and
Estimated delivery dates are estimates only. Int'l customers allow a few more days. For more precise delivery estimates, please contact us at support@plc-direct.com. Contact us in advance for expedited shipping options.
Condition:
€0,00
€4.689,95
€0,00

Ach Direct Debit American Express Apple Pay Diners Club Discover Google Pay Mastercard PayPal Shop Pay Visa
