Lenze's E84AYCPMV is a dedicated PROFIBUS module intended for use with 8400 inverter drives. This device enhances communication within industrial networks by supporting both PROFIBUS DP-V0 and DP-V1 profiles, ensuring seamless data transfer across multiple devices. The module is fitted with a 9-pin Sub-D connector, providing a reliable physical interface for connection.

Operating via RS485 bus coupling, this module supports a network topology that can be either line or tree structured, with the option to include repeaters. It accommodates communication speeds ranging from 9.6 kbps to 12 Mbps, automatically adjusting to optimize transmission efficiency. The configuration allows for quick setup, capable of managing up to 31 slave devices without any repeaters, or expanding to a maximum of 125 slaves when deployed with repeaters.

For convenience in system design and use, the E84AYCPMV supports customizable station addressing through the use of either DIP switches or software, allowing for addressing of 1 through 126. The module features five diagnostic LEDs, assisting users in monitoring operational status and troubleshooting potential issues. Each direction is capable of handling 16 process data words, providing ample data exchange capabilities for various applications.

The product is CE and UL certified, confirming its compliance with industry safety standards. It operates with protective insulation in accordance with EN 61800-5-1, ensuring reliability in demanding environments. The module is powered directly by the associated inverter drive, conveniently eliminating the need for separate power supply arrangements. Additionally, it is coated for enhanced environmental protection, significantly increasing its durability against industrial challenges.

The Lenze E84AYCERV inverter drive is part of the Series 8400 and emphasizes connectivity and reliable performance. As a PROFINET inverter drive, it efficiently utilizes a power supply voltage of 24 V DC, requiring a current of 140 mA.

The communication interface has an RJ45 Ethernet connection, adhering to IEEE 802.3 and 100Base-TX standards. This enables communication across network layouts like tree, star, and line configurations. The drive facilitates optimized data transfer with a switching mode that supports store and forward operations. It features a switching delay of roughly 125 microseconds, ensuring timely communications.

Utilizing CAT 5e S/FTP cables as the communication medium, the E84AYCERV supports a data rate of 100 Mbps and can accommodate up to 255 nodes per subnet. Its compact design measures 67 x 50 x 57 mm, making it suitable for diverse installation environments.

The drive has been certified under multiple regulatory standards, including CE, UL 508C, and TR CU 004/2011 and 020/2011, ensuring its reliability and safety in various applications. The data handling times for process data and parameter data are approximately 2 ms and 30 ms, respectively, allowing for efficient interaction with connected systems.
