ABB

1SAP576100R0001 ABB

Additional Information

ABB Type Designation:
CP676
Ambient Air Temperature:
Operation 0 ... +50 °C
Storage -20 ... +70 °C
Operation 0 ... +50 °C
Storage -20 ... +70 °C
CN8:
85371091
Communication Interface:
2x Ethernet 10/100Mbit
1x RS-232/-422/-485
2x USB 2.0 Host
1x SD-card slot
2x Expansion slot
2x Ethernet 10/100Mbit
1x RS-232/-422/-485
2x USB 2.0 Host
1x SD-card slot
2x Expansion slot
Country or Territory of Origin:
Italy
Germany
Italy
Germany
Customs Tariff Number:
85371091
Degree of Protection:
acc. to IEC 60529 Front IP66
acc. to IEC 60529 Housing IP20
acc. to IEC 60529 Front IP66
acc. to IEC 60529 Housing IP20
EAN:
4013614493171
Frame Size:
Undefined
GL Certificate:
Gross Weight:
4.9 kg
Housing Material:
Front side: Aluminium
Reverse side: Aluminium
Front side: Aluminium
Reverse side: Aluminium
Invoice Description:
CP676 Control Panel 15" TFT touch screen
Made To Order:
No
Memory Size User Data:
256 MB
Memory Size User Program:
256 MB
Memory Type User Data:
Flash Disk
Memory Type User Program:
DDR RAM
Minimum Order Quantity:
1 piece
Mounting Type:
Front face
Order Multiple:
1 piece
Package Level 1 Depth / Length:
510 mm
Package Level 1 Height:
145 mm
Package Level 1 Units:
1 carton
Package Level 1 Width:
410 mm
Power Consumption (@Pcons):
34 W
Power Supply:
24 (18 ... 30) V DC
Product Main Type:
CP676
Product Name:
Control Panels
Product Net Depth / Length:
64 mm
Product Net Height:
307 mm
Product Net Weight:
3.3 kg
Product Net Width:
392 mm
Product Type:
PLC-CP600
Programming Software:
PB610 Panel Builder 600
Quote Only:
No
Real-time Clock:
Hardware clock, battery back-up
Replaced Product ID (OLD):
SCIP:
8ed3b3fc-07b0-437a-89a8-26d502a64d2c Germany
Screen Color:
64k colors
Screen Resolution:
1024 x 768 pixel
Screen Size:
4:3 screen 15 in
Screen Type:
TFT color, LED backlight, touch screen
Security:
Password protection with 8 user levels
Selling Unit of Measure:
piece
Serial Port 1 Type:
RS232/RS422/RS485
Service Life:
40000 hour
Short Description:
CP676 Control Panel 15" TFT touch screen
Stocked At (Warehouses):
Menden, Germany
Hangzhou, China
Bairro Santo Antonio, Brazil
Menden, Germany
Hangzhou, China
Bairro Santo Antonio, Brazil
UNSPSC:
32151703
USB Port 1 Type:
Host, version 2.0
USB Port 2 Type:
Host, version 2.0
WEEE B2C / B2B:
Business To Business
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
eClass:
27-33-02-01

Sale price$2,802.50
1-year warranty
FREE WORDWIDE SHIPPING
Est. delivery between and
Estimated delivery dates are estimates only. Int'l customers allow a few more days. For more precise delivery estimates, please contact us at support@plc-direct.com. Contact us in advance for expedited shipping options.
Condition:
$2,802.50
$0.00
$2,159.92

Ach Direct Debit American Express Apple Pay Diners Club Discover Google Pay Mastercard PayPal Shop Pay Visa
