2CTB815710R2300 ABB - OVR T1-T2 4L 12.5-275s P QS
ABB

2CTB815710R2300 ABB - OVR T1-T2 4L 12.5-275s P QS

ABB EcoSolutions

Environmental Product Declaration - EPD:

Technical

Type of Low Voltage Distribution System:
TN-S
Suitable For:
To protect the systems against the transient overvoltage (lightning)
Nominal AC Voltage of the System (Uo):
230 / 400 V
Maximum Continuous Operating Voltage (Uc):
(L-PE) 275 V
(L-L) 440 V
(L-N) 440 V
(N-PE) 275 V
(L-PE) 275 V
(L-L) 440 V
(L-N) 440 V
(N-PE) 275 V
Temporary Overvoltage Test Value (UT):
337 V
Discharge Current:
Nominal 20 kA
Maximum 80 kA
Total 320 kA
Nominal 20 kA
Maximum 80 kA
Total 320 kA
Impulse Current:
I (imp, 10 / 350 µs) 12.5 kA
I (total, 10 / 350 µs) 50 kA
I (imp, 10 / 350 µs) 12.5 kA
I (total, 10 / 350 µs) 50 kA
Lightning Impulse Current:
12.5 kA
Short Circuit Withstand Icc:
100 kA
Follow Current Extinction Capacity If (I fi):
(L-N) - kA
(N-PE) - kA
(L-N) - kA
(N-PE) - kA
Short-Circuit Protective Devices:
Curve B Breakers ≤ 125 A
Curve C Breakers ≤ 125 A
gL Type Fuses ≤ 160 A
gG Type Fuses ≤ 160 A
Curve B Breakers ≤ 125 A
Curve C Breakers ≤ 125 A
gL Type Fuses ≤ 160 A
gG Type Fuses ≤ 160 A
Arrester Class:
I
II
I
II
Number of Protected Poles:
4
Number of Poles:
4P
Position of Neutral Terminals:
Right
Version:
Plug-in
Product Type:
QS
Options Provided:
Industry, commercial building
Preventive Maintenance Feature:
Yes
Status Indicator:
Yes
Fuse Size:
4 modular spacing

Electrical

Voltage Protection Level ( Up):
(L-N) 2.8 kV
(N-PE) 1.4 kV
(L-PE) 1.4 kV
(L-N) 2.8 kV
(N-PE) 1.4 kV
(L-PE) 1.4 kV
Power Loss:
63 mW

Material Compliance

RoHS Status:
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
RoHS Date:
20230707
REACH Information:
False - does not contain substances > 0.1 mass percentage
REACH Date:
20231212
Conflict Minerals Reporting Template (CMRT):
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B:
Business To Business

Environmental

Degree of Protection:
IP20
Maximum Operating Altitude Permissible:
Without Derating 5000

Dimensions

Width in Number of Modular Spacings:
4
Product Net Width:
71.2 mm
Product Net Height:
88 mm
Product Net Depth / Length:
76.7 mm
Product Net Weight:
0.6 kg

Ordering

Package Level 1 Units:
box 1 piece
Package Level 1 Gross Weight:
0.600 kg
E-Number (Finland):
3217623

Certificates and Declarations

CQC Certificate:
Declaration:

Installation

Mounting Type:
DIN-Rail

External Classifications and Standards

ETIM 9:
EC001457 - Combined arrester for power supply systems
ETIM 10:
EC001457 - Combined arrester for power supply systems
eClass:
V11.0 : 27130808
Object Classification Code:
141BCC
Standards:
IEC 61643-11 / EN 61643-11
Description
Warranty
Shipping and Return

ABB EcoSolutions

Environmental Product Declaration - EPD:

Technical

Type of Low Voltage Distribution System:
TN-S
Suitable For:
To protect the systems against the transient overvoltage (lightning)
Nominal AC Voltage of the System (Uo):
230 / 400 V
Maximum Continuous Operating Voltage (Uc):
(L-PE) 275 V
(L-L) 440 V
(L-N) 440 V
(N-PE) 275 V
(L-PE) 275 V
(L-L) 440 V
(L-N) 440 V
(N-PE) 275 V
Temporary Overvoltage Test Value (UT):
337 V
Discharge Current:
Nominal 20 kA
Maximum 80 kA
Total 320 kA
Nominal 20 kA
Maximum 80 kA
Total 320 kA
Impulse Current:
I (imp, 10 / 350 µs) 12.5 kA
I (total, 10 / 350 µs) 50 kA
I (imp, 10 / 350 µs) 12.5 kA
I (total, 10 / 350 µs) 50 kA
Lightning Impulse Current:
12.5 kA
Short Circuit Withstand Icc:
100 kA
Follow Current Extinction Capacity If (I fi):
(L-N) - kA
(N-PE) - kA
(L-N) - kA
(N-PE) - kA
Short-Circuit Protective Devices:
Curve B Breakers ≤ 125 A
Curve C Breakers ≤ 125 A
gL Type Fuses ≤ 160 A
gG Type Fuses ≤ 160 A
Curve B Breakers ≤ 125 A
Curve C Breakers ≤ 125 A
gL Type Fuses ≤ 160 A
gG Type Fuses ≤ 160 A
Arrester Class:
I
II
I
II
Number of Protected Poles:
4
Number of Poles:
4P
Position of Neutral Terminals:
Right
Version:
Plug-in
Product Type:
QS
Options Provided:
Industry, commercial building
Preventive Maintenance Feature:
Yes
Status Indicator:
Yes
Fuse Size:
4 modular spacing

Electrical

Voltage Protection Level ( Up):
(L-N) 2.8 kV
(N-PE) 1.4 kV
(L-PE) 1.4 kV
(L-N) 2.8 kV
(N-PE) 1.4 kV
(L-PE) 1.4 kV
Power Loss:
63 mW

Material Compliance

RoHS Status:
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
RoHS Date:
20230707
REACH Information:
False - does not contain substances > 0.1 mass percentage
REACH Date:
20231212
Conflict Minerals Reporting Template (CMRT):
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B:
Business To Business

Environmental

Degree of Protection:
IP20
Maximum Operating Altitude Permissible:
Without Derating 5000

Dimensions

Width in Number of Modular Spacings:
4
Product Net Width:
71.2 mm
Product Net Height:
88 mm
Product Net Depth / Length:
76.7 mm
Product Net Weight:
0.6 kg

Ordering

Package Level 1 Units:
box 1 piece
Package Level 1 Gross Weight:
0.600 kg
E-Number (Finland):
3217623

Certificates and Declarations

CQC Certificate:
Declaration:

Installation

Mounting Type:
DIN-Rail

External Classifications and Standards

ETIM 9:
EC001457 - Combined arrester for power supply systems
ETIM 10:
EC001457 - Combined arrester for power supply systems
eClass:
V11.0 : 27130808
Object Classification Code:
141BCC
Standards:
IEC 61643-11 / EN 61643-11
