Description
The Lenze EVS9322-CKV003 operates as a precise servo cam profiler with a power capacity of 0.75 kW, equivalent to 1 horsepower. This compact controller is versatile, allowing for inverter switching frequencies set at either 8 kHz or 16 kHz, accommodating varying application requirements.
When the inverter operates at 8 kHz, it delivers a nominal output current of 2.5 A, peaking at 3.75 A. Alternatively, at 16 kHz, the nominal output reduces to 1.8 A, with a maximum peak output current of 2.7 A. The idle current at 8 kHz is recorded as 3.8 A, which reflects its efficiency in low-demand scenarios.
The input voltage for the controller ranges from 320 V to 440 V AC, providing flexibility for installation in different environments. It also accepts an input frequency range of 45 to 65 Hz. For applications that require it, the EVS9322-CKV003 supports an alternative DC input voltage ranging from 450 to 620 V DC.
In terms of output performance, this controller produces output voltage that reaches 94% of the supply voltage when utilized with a mains choke. Without the mains choke, the output voltage matches the supply voltage directly. Energy loss during operation is recorded at 110 W.
Finally, in the event of overcurrent conditions, the device reduces its output current to 70% of its nominal rating to prevent damage, ensuring reliability under stress. The Lenze EVS9322-CKV003 combines reliability and versatility, making it suitable for various application demands.
Technical specifications for EVS9322-CKV003
| Manufacturer | Lenze |
|---|---|
| Series | Series 9300 |
| Part Number | EVS9322-CKV003 |
| Controller Type | Servo cam profiler |
| Power Capacity | 0.75 kW (1 hp) |
| Inverter Switching Frequency Options | 8 kHz, 16 kHz |
| Nominal Output Current at 8 kHz | 2.5 A |
| Peak Output Current at 8 kHz | 3.75 A |
| Idle Current at 8 kHz | 3.8 A |
| Nominal Output Current at 16 kHz | 1.8 A |
| Peak Output Current at 16 kHz | 2.7 A |
| Input Voltage Range | 320-440 V AC |
| Input Frequency Range | 45-65 Hz |
| Alternative DC Input Voltage | 450-620 V DC |
| Output Voltage (Using Mains Choke) | 94% of supply voltage |
| Output Voltage (Without Mains Choke) | Equal to supply voltage |
| Energy Loss | 110 W |
| Reduced Current During Overcurrent | 70% of nominal current |
